Silver base brazing filler metals, with excellent processing property, optimal melting temperature, good wetting and seam-forming property, high joint strength and ductility,good corrosion resistance, have been widely used in brazing mild steel, stainless steel, Structural Steel, refractory alloys, copper and its alloys, cemented carbides and Kovar alloys,etc.In order to improve performance and satisfy the increasingly serious technical requirement,the silver base filler metal we usually use is added Sn, Ni, Si, Mn, In, Ga to form Ag-Cu-Zn-Sn, Ag-Cu-Zn-Ni, Ag-Cu-Zn-Mn, Ag-Cu-Zn-X(Ga, Sn, In, Ni) series product and so on.
Attention:The residue such as grease,oxide etc on the surface and connection must be removed strictly before the brazing.
中国标准牌号 Chinese Standard |
相当牌号 Equivalent Grade |
化学成分(Wt%) Composition |
熔化温度范围(℃) Melting Range |
主要特性及用途 Characteristics and Application |
||||||
产品样本牌号 | AWS A5.8 | Ag | Cu | Zn | Sn | 其他 Rest |
固相线 Solidus |
液相线 Liquidus |
||
B-Ag10CuZn | 料301 | ___ | 9.0 ~ 11.0 |
52.0 ~ 54.0 |
36.0 ~ 38.0 |
___ | ___ | 815 | 850 | 价格便宜,熔点较高,钎焊接头延性较差,用于钎焊要求较低的铜及铜合金、钢等。 |
B-Ag25CuZn | 料302 | ___ | 24.0 ~ 26.0 |
40.0 ~ 42.0 |
33.0 ~ 35.0 |
___ | ___ | 700 | 800 | 用于要求钎缝表面粗糙度细,强度高,振动载荷的工件,钎料具有良好的润湿作用和填充能力,钎焊铜及铜合金、钢和不锈钢等。 |
B-Ag30CuZn | ___ | BAg-20 | 29.0 ~ 31.0 |
37.0 ~ 39.0 |
30.0 ~ 34.0 |
___ | ___ | 677 | 766 | 漫流性好,钎焊铜及铜合金、钢及不锈钢等,接头强度高。 |
B-Ag45CuZn | 料303 | BAg-5 | 44.0 ~ 46.0 |
29.0 ~ 31.0 |
23.0 ~ 27.0 |
___ | ___ | 665 | 745 | 熔点低,润湿性及填缝能力好,接头强度高,能承受振动载荷,在电子、电力和食品等行业中得到广泛应用。 |
B-Ag50CuZn | 料304 | BAg-6 | 49.0 ~ 51.0 |
33.0 ~ 35.0 |
14.0 ~ 18.0 |
___ | ___ | 690 | 775 | 用于要求钎缝表面粗糙度细,强度高,能承受振动载荷的工件,且可用于钎焊间隙不均匀或圆角较大的零件。 |
B-Ag70CuZn | ___ | BAg-10 | 69.0 ~ 71.0 |
19.0 ~ 21.0 |
8.0 ~ 12.0 |
___ | ___ | 690 | 740 | 熔点低,润湿性及填缝能力好,接头强度高,能承受振动载荷,钎缝表面光滑,特别适宜于钎焊要求导电性高的工件。 |
B-Ag25CuZnSn | ___ | BAg-37 | 24.0 ~ 26.0 |
39.0 ~ 41.0 |
31.0 ~ 35.0 |
1.5 ~ 2.5 |
___ | 688 | 780 | 漫流性好,钎缝较光洁,钎焊铜及铜合金、银镍合金、钢及不锈钢。 |
B-Ag30CuZnSn | 料310 | ___ | 29.0 ~ 31.0 |
35.0 ~ 37.0 |
30.0 ~ 34.0 |
1.5 ~ 2.5 |
___ | 650 | 750 | 熔点低,漫流性好,可钎焊铜及铜合金、钢及不锈钢、邦迪管等。 |
B-Ag34CuZnSn | ___ | ___ | 33.0 ~ 35.0 |
35.0 ~ 37.0 |
25.0 ~ 29.0 |
2.5 ~ 3.5 |
___ | 630 | 730 | 熔点低,润湿性及填缝性较好,可钎焊铜及铜合金,碳钢、不锈钢及邦迪管等。 |
B-Ag40CuZnSnNi | 料322 | ___ | 39.0 ~ 41.0 |
24.0 ~ 26.0 |
29.5 ~ 31.5 |
2.7 ~ 3.3 |
Ni 1.30 ~ 1.65 |
634 | 640 | 熔点低,镍和锡的加入可替代镉的作用,一般用于钎焊铜及铜合金,碳钢、不锈钢等。 |
B-Ag56CuZnSn | 料316 | BAg-7 | 55.0 ~ 57.0 |
21.0 ~ 23.0 |
15.0 ~ 19.0 |
4.5 ~ 5.5 |
___ | 620 | 650 | 替代含镉银钎料,用于钎焊铜、钢、镍及其合金,一般用于食品行业或需要颜色匹配场合。 |
B-Ag30CuZnIn | ___ | ___ | 29.0 ~ 31.0 |
37.0 ~ 39.0 |
25.5 ~ 28.5 |
___ | In 4.5 ~ 5.5 |
640 | 755 | In的加入降低了熔点,提高了钎料的流动性和润湿性,一般用于制冷压缩机铜和钢的钎焊。 |
B-Ag34CuZnIn | ___ | ___ | 33.0 ~ 35.0 |
34.0 ~ 36.0 |
28.5 ~ 31.5 |
___ | In 0.8 ~ 1.2 |
660 | 740 | 熔点低,流动性和润湿性较好,常用于代替BAg34CuZnSn在制冷压缩机制造中钎焊铜和钢。 |
B-Ag40CuZnIn | ___ | ___ | 39.0 ~ 41.0 |
29.0 ~ 31.0 |
23.5 ~ 26.5 |
___ | In 4.5 ~ 5.5 |
635 | 715 | 熔点较低,流动性和润湿性好,常用于代替BAg45CuZn在制冷压缩机制造中钎焊铜和钢。 |
